Sistemi di ispezione per contenitori vuoti
Inspection systems for empty containers

M&M News
Per le linee di pet food Dolma (gruppo Mars) di Belgioioso, Parmacontrols ha messo a punto una versione particolare del sistema di visione ControlCamera, che ispeziona le scatole vuote, rilevando ammaccature sul bordo, appiattimento della flangia, deformazioni della forma, punte sulle flange e lattine rovesciate.

Nelle linee di pet food, come in generale in quelle per la produzione di conserve, vengono spesso impiegate, per ovvi motivi di economicità, scatole di banda stagnata dallo spessore molto ridotto. Quando ricevono dei colpi, tuttavia, tali scatole si deformano, evenienza resa più probabile dalle elevate velocità raggiunte sulle linee più moderne. Le lattine deformate provocano, di norma, un fermo di parecchi minuti della macchina riempitrice o aggraffatrice, con gravi ripercussioni sull’efficienza totale di linea. A una velocità di 800 /1000 lattine al minuto (di diametro 73 e 99 mm, varie altezze), infatti, bastano anche pochi minuti a ridurre in maniera sensibile la produttività.
Al fine di evitare questi inconvenienti, il sistema di visione ControlCamera messo a punto da Parmacontrols effettua il monitoraggio delle scatole vuote movimentate in fila singola su nastro, per verificarne ovalità, ammaccature e difettosità della flangia, e attiva le funzioni di espulsione. In particolare, lo scarto delle scatole con flangia deformata permette di evitare l’output di lattine con aggraffatura difettosa, che quindi non sono in grado di mantenere l’integrità del prodotto per tutto il periodo di conservazione previsto.
Dopo le prime settimane di uso del sistema, che lavora a 850 cpm, il cliente ha segnalato un aumento molto rilevante dell’efficienza complessiva della linea. Inoltre, ha apprezzato particolarmente il servizio di teleassistenza, grazie a cui è possibile effettuare just-in-time, dagli uffici Parmacontrols, ogni intervento sul software.

Le caratteristiche del sistema di visione
ControlCamera è un sistema di visione con telecamera, attrezzato di box ottico nell’apposito contenitore completo di staffaggio alle fiancate del nastro, con dispositivo manuale di regolazione per il cambio formato. Il box ottico comprende il sistema di illuminazione e il montaggio regolabile di una o più telecamere CCD ad alta risoluzione, nonchè i dispositivi di filtraggio o concentrazione luce e/o immagini eventualmente necessari. La parte elettronica prevede un PC dedicato in apposito rack inserito in quadro di controllo separato, fornito con gruppo di continuità. Il sistema è equipaggiato di monitor TFT, con tastiera a membrana per l’interfaccia operatore, e dello speciale software Parmacontrols, sviluppato in ambiente Windows, da adattare ad ogni singola applicazione con la messa a punto di algoritmi specifici.
Le specifiche di ispezione sono: ammaccatura rilevante del bordo; flangia appiattita (deformazione superiore a 1 mm in verticale, e a 2 mm in orizzontale); lattina ovalizzata (diametro piccolo/diametro grande < 0,95); lattina piegata/ammaccata; punte sulle flange (deformazione superiore a 1 mm in verticale, e a 2 mm in orizzontale); lattine rovesciate.
La velocità operativa di ControlCamera varia a seconda del tipo di controllo necessario; la sensibilità supera 0,01 mm e dipende dalla grandezza del campo di ispezione e anche la precisione operativa - definibile dopo la prova con campioni effettivi - è diversa in relazione al tipo di controllo.
Il sistema di visione della Parmacontrols può essere interfacciato con il software di rilevamento dati ControlData e collegato via modem per le funzioni di teleassistenza. Inoltre, è possibile l’inserimento di più sistemi di ispezione in rete locale, con server per centralizzazione dati e settaggi in remoto.

Funzioni standard
Controllo di 1 oppure 2 espulsori tipo ControlEjector STD, Multisize, Multipush a dieci settori oppure segnale di fault a sistema esterno (velocità del nastro fissa). Allarme con fermo macchina dopo un numero di scarti consecutivi impostabile (logica x : y), sia per il controllo principale che per le eventuali ispezioni supplementari. Visualizzazione di velocità in metri/minuto e confezioni/ora, dei conteggi totale contenitori / totale scarti per causa. Esclusione espulsore sia da software che con selettore a quadro. Segnale di buon funzionamento sistema per collegamento con logiche esterne. Interfaccia optoisolata RS 232 per scarico dati a sistemi esterni per elaborazione statistica o a stampante in locale/remoto. Torretta di segnalazione a luce rosso/verde per indicazione immediata dello stato di funzionamento. Memorizzazione settaggio di 20 differenti prodotti. Accesso ai diversi menu di settaggio con password a più livelli (operatore, responsabile, tecnico abilitato).

Opzioni
Architettura hardware basata su Windows CE. Interfaccia operatore con touchscreen. Fino a 5 ispezioni supplementari in blocco con la stazione principale o anche in remoto. Encoder e relativo upgrade del software di controllo espulsore (per nastri a velocità variabile). Impostazione della quantità del lotto da produrre con segnale in uscita al suo completamento. Allarme scarti periodici. Interfaccia RS 422 optoisolata. Printer seriale ad aghi termici per ottenere stampe in locale. Software bilingue (italiano e una tra le principali lingue europee). Funzionamento come terminale remoto per operatore. Staffe e piastre di fissaggio a terra con piedi supplementari oppure staffa intera per fissaggio a terra indipendente, sia per box ottico che per quadro PC.
Inspection systems for empty containers
For Belgioioso’s lines of Dolma pet food (part of the Mars Group), Parmacontrols has developed
a special version of its ControlCamera vision system: this inspects the empty cans, checking for dents around the edges, flattened flanges, deformed shape, sharp points on the flanges and upturned cans.

Very thin cans are often used for lines of pet food, as for the production of preserves in general, for obvious reasons of cost. When these are hit, however, the cans become dented, and this is made even more probable due to the high speeds of the latest production lines. As a general rule, dented cans cause stoppages lasting a few minutes for the filling machine or double seamer, with serious repercussions on the efficiency of the entire line. In fact, when working at a speed of 800 -100 cans per minute (73 and 99 mm in diameter, various height), just a few minutes are enough to reduce productivity levels significantly.
To avoid these problems, the ControlCamera vision system has been developed by Parmacontrols to monitor the empty cans travelling in single file on the conveyor belt, checking for ovalized cans, dents and defects in the flange, and to activate the ejection function as required. In particular, by rejecting cans with deformed flanges it’s possible to avoid the output of cans with defective seams that are not able to protect the product properly during that product’s given shelf-life.
After the first few weeks of using this system, running at 850 cpm, the customer has reported a very significant increase in the overall efficiency of the line. What’s more, the remote assistance service is particularly appreciated, thanks to which the Parmacontrols office can effect just-in-time interventions on the software.

The characteristics of the vision system
The ControlCamera is a vision system with TV camera, an optical box in the special case with brackets for installation alongside the conveyor belt and a manual recording device for the size change. The optical box includes a lighting system and adjustable assembly of one or more high resolution CCD TV cameras, as well as filtering devices and light and/or images concentrators as required. The electronics includes a dedicated PC in a special rack inside the separate control panel with its own continuity unit. The system is also equipped with a TFT monitor, touch-screen keyboard for operator interface and special Parmacontrols software, running in Windows, that can be adapted to each application with the development of specific algorithms.
The inspection specifications are: obvious denting of edges; flattened flanges (deformed by more than 1 mm vertically and 2 mm horizontally); ovalized cans (small diameter/big diameter < 0.95); bent or dented cans; sharp points on flanges (deformed
by more than 1 mm vertically
and 2 mm horizontally); upturned cans. The working speed of the ControlCamera varies to suit the type of control required; sensitivity is more than 0.01 mm and depends on the size of the inspection field and also the working precision - this is defined after tests with proper samples - varies to suit the type of control required.
The Parmacontrols vision system can be interfaced with the ControlData data detection software and connected via modem for remote assistance services. Moreover, several inspection systems can be installed in a local network, with a server to centralise the data and for remote setting.

Standard functions
Control of 1 or 2 ejectors (ControlEjector STD, Multisize, ten-sector Multipush) or the fault signal sent to an external system (fixed belt speed). Alarm with a machine stoppage after a set number of consecutive rejects (x : y logic), both for the main control and for any additional inspections. Display of the speed in metres/minute and packs/hour, of the total count of containers/total rejects by cause. Exclusion of the ejector either by software or with a selector switch on the control panel. System OK signal for connection to external logics. RS 232 optoinsulated interface for data download to external systems in order to compile statistics or to a local/remote printer. Red/green warning light tower for immediate indication
of current working status. Saving of settings for 20 different products.
Access to different setting menus via password on several levels (operator, manager, qualified technician).

Options
Hardware architecture based on Windows CE. Operator interface with touch-screen. Up to 5 extra inspections in a block with the main station or even in remote mode. Encoder and relative upgrade of the ejector control software (for variable speed belts). Setting of the quantity of the lot to be produced with output signal on completion. Regular reject alarm. RS 422 optoinsulated interface. Thermal needle serial printer to get local printouts. Software in two languages (Italian and a choice of the main European languages). Functioning as a remote operator terminal. Brackets and plates for anchoring to the ground with extra feet or a complete independent anchoring bracket, both for the optical box and the PC panel.
